Premium Quality • ISI Certified
Fire Resistant Cable
Sumo Cables Fire Resistant Cables are life-safety cables designed to maintain circuit integrity during fire emergencies. These cables feature special mica tape wrapping around each conductor that forms a protective ceramic layer when exposed to fire, allowing the cable to continue operating even at temperatures up to 950°C for 180 minutes. Essential for emergency evacuation systems, fire alarms, and critical safety circuits.
Key Features
- Maintains circuit integrity during fire (up to 950°C)
- Mica tape fire barrier on each conductor
- Fire survival time: 180 minutes minimum
- LSZH (Low Smoke Zero Halogen) sheath
- Copper conductors for reliability
- Suitable for critical safety circuits
- Voltage rating up to 1.1 kV
- Meets BS 6387 Category CWZ standards
Technical Specifications
| Conductor Material | Annealed Copper (Stranded) |
| Insulation | XLPE / EPR |
| Fire Barrier | Mica Tape Wrap |
| Outer Sheath | LSZH |
| Voltage Rating | 600/1000V (1.1 kV) |
| Core Configuration | 2 Core to 61 Core |
| Size Range | 1.5 sq.mm to 400 sq.mm |
| Fire Survival | 180 minutes at 950°C |
| Standards | BS 6387 (CWZ), IEC 60331 |
Applications
Emergency Lighting Systems
Fire Alarm and Detection Systems
Smoke Extraction Controls
Emergency Evacuation Systems
Sprinkler System Wiring
Critical Safety Circuits in Buildings
